HydroFlame-X™

(Typical values — not specifications)

• Appearance (wet): Opaque to milky liquid; tintable
• Specific Gravity: ±1.05 g/cm³
• pH: 6.8 – 7.2
• VOC: < 10 g/L
• Flash Point: Non-flammable (water-based)
• Finish: Low sheen to matte
• Touch Dry: ±45 minutes @ 25 °C
• Re-coat: 1 – 3 hours
• Full Cure: 24 – 48 hours
• Coverage: 6 – 8 m²/L per coat (substrate dependent)
• System Build: Minimum 2 coats (~80 μm DFT total)
• Packaging: 5 L and 20 L HDPE containers
• Shelf Life: 24 months (sealed, 5–25 °C)

• Substrates must be clean, dry, and free of dust, grease, oil, rust, or loose material
• Moisture content of porous substrates must be below 12%
• Previously coated surfaces should be lightly abraded to ensure mechanical adhesion
• Remove rust and scale from steel prior to application
• Timber surfaces must be free of oils or treatments that may inhibit adhesion

• Apply by brush, roller, airless spray, or HVLP
• Ready to use; do not dilute unless absolutely necessary (max 5% clean water)
• Apply minimum 2 coats; 3 coats recommended for high-risk or high-humidity environments
• Application temperature: 10–35 °C
• Relative humidity: below 80%
• Avoid condensation during application
• Clean tools with warm water before curing

HydroFlame-X™ may be applied to properly prepared:

• Timber and plywood
• Fibre cement and drywall
• Concrete and masonry
• Steel (prepared)
• Composite building panels
• Thatch roofing (specialist high-pressure spray application required)
• Roof slabs and structural elements requiring thermal-assist coating

Practical field evaluations have demonstrated the product’s ability to limit flame spread and reduce sustained combustion on treated timber substrates when exposed to direct flame sources.
Observed outcomes under controlled field testing included:

• Localised surface charring
• Limitation of flame propagation
• Self-extinguishing behaviour after removal of flame source

Note: These observations are based on practical field evaluation and do not constitute formal fire classification or laboratory certification under SANS, BS, or EN standards. Independent certification testing is pending. Users must conduct application-specific testing appropriate to their risk profile.

• Not intended for continuous immersion or submerged conditions
• Not a fireproofing system
• Direct point-of-flame contact will result in surface charring
• Does not replace certified fire-rated systems unless tested as part of an approved assembly
• Formal fire certification under SANS/BS/EN standards is pending
• Thatch treatment maintenance interval: up to 3 years depending on exposure

• Non-toxic and non-flammable in liquid form
• Free of halogens and heavy metals
• Use gloves and eye protection during application
• Ensure adequate ventilation
• Refer to Safety Data Sheet SDS-HFX-002 for complete safety and disposal information

HydroFlame-X™ is manufactured by a third-party manufacturer.
Larik Solutions Pty Ltd t/a WATERPROOFING SOUTH AFRICA acts solely as the supplier and distributor of this product and is not the manufacturer.
This product is a protective coating designed to assist in limiting flame spread and moisture ingress. It is not certified as a fire-rated or fireproofing system unless explicitly stated in writing.

HydroFlame-X™ is manufactured by a third-party manufacturer.
Larik Solutions Pty Ltd t/a WATERPROOFING SOUTH AFRICA acts solely as the supplier and distributor of this product and is not the manufacturer.

The manufacturer warrants that HydroFlame-X™ conforms to its published product specifications at the time of manufacture. This warranty is limited to a period of five (5) years from the date of purchase, provided that the product is stored, prepared, applied, and maintained strictly in accordance with the manufacturer’s written guidelines, including the application of a maintenance coat within the third year of service life where specified.

No further warranties, express or implied, including but not limited to merchantability or fitness for a particular purpose, are given by either the manufacturer or the supplier.

As application methods, substrate conditions, workmanship, environmental exposure, and service conditions are beyond the control of both the manufacturer and Larik Solutions Pty Ltd t/a WATERPROOFING SOUTH AFRICA, no responsibility can be accepted for results obtained or for any direct, indirect, incidental, or consequential loss or damage arising from the use or misuse of this product.

HydroFlame-X™ is a protective coating and not a certified fire-resistant or fire-rated system. Performance may vary depending on substrate, film thickness, surface preparation, and environmental conditions. Users are required to conduct their own evaluation and testing to determine suitability for the intended application.


By purchasing, using, or applying HydroFlame-X™, the user acknowledges and agrees that:

• The product has not undergone formal third-party certification testing unless expressly stated otherwise in writing.
• Any fire-protective or hydrophobic performance characteristics are based on internal development data and field observations.
• The user assumes full responsibility for verifying product suitability, regulatory compliance, and performance for their specific application.
• Neither the manufacturer nor Larik Solutions Pty Ltd t/a WATERPROOFING SOUTH AFRICA shall be held liable for any direct, indirect, incidental, or consequential loss or damage, including but not limited to property damage, equipment failure, or personal injury arising from the use, misuse, or incorrect application of the product.
• All risk associated with the use and performance of the product rests entirely with the user, and use of the product constitutes full acceptance of this indemnity.
